23 SALTIGA

Daiwa’s Monocoque (MQ) body is a revolutionary design that redefines spinning reels. Unlike traditional two-part reel bodies, MQ technology features a rigid, one-piece construction that enhances strength, reduces weight, and improves weather sealing. By eliminating the need for a screw-secured sideplate, space is freed up within the body, allowing for the integration of a larger drive gear—up to 85% of the body’s surface area. This results in increased power, durability, and efficiency without making the reel larger. The MQ body serves as a stiff, distortion-proof frame, ensuring exceptional durability even under extreme conditions. The direct screw-in engine plate replaces the traditional sideplate, reducing excess material and reinforcing the reel’s structure. This balance between lightness and strength creates a reel that is compact yet incredibly powerful. A key benefit of MQ technology is the ability to house a significantly larger drive gear, improving torque, power transmission, and longevity. With increased strength and reduced weight, MQ reels offer a smoother, more efficient fishing experience. Daiwa’s innovation in reel design continues to push boundaries, delivering stronger and more compact reels for all anglers.

AIRDRIVE DESIGN – Lightness, Power & Precision Combined: AIRDRIVE DESIGN represents Daiwa’s cutting-edge innovation in spinning reel engineering, built around four core components—AIRDRIVE ROTOR, AIRDRIVE BAIL, AIRDRIVE SPOOL, and AIRDRIVE SHAFT. This integrated system delivers unmatched lightness, responsiveness, and control to elevate the angling experience. The AIRDRIVE ROTOR, made from lightweight ZAION material, is 16% lighter than previous designs, reducing inertia for smoother, more responsive rotation. The AIRDRIVE BAIL, featuring a slimmer, hollow structure, cuts weight by 33%, improving line flow and minimizing tangles. AIRDRIVE SPOOL contributes to overall weight reduction and balance while enhancing oscillation performance. The AIRDRIVE SHAFT, with its non-contact design supported by dual bearings, minimizes friction for quieter rotation and improved torque. Together, these technologies deliver refined lure control, effortless casting, and powerful reeling—setting a new benchmark in spinning reel design.

Low inertia is the key.
The newly developed AIRDRIVE ROTOR is made from ZAION. Maintaining the strength of the rotor from 18 EXIST, DAIWA has been able to reduce the weight significantly. Designed with focus to create a perfectly round structure, trouble free and flawless rotation have been achieved.
The rotor unit itself has seen a 16% weight reduction compared to the previous model (Based on 2500 size reel) and will set the standard for what future rotor design of small spinning reels will be.

Trouble free future.
DAIWA has constructed a bail smaller in diameter whilst providing required strength to achieve a further weight reduction to the front unit. In comparison to 18 EXIST, AIRDRIVE BAIL reduces the weight of the bail by 33% (compared to 2500 size).
DAIWA has adjusted the angle of bail setting to improve the line movement into the roller. Careful attention was given to the roller and slider and individual design alterations were done for each size of 22 EXIST, perfectly adjusting the line management for each size of the reel.

Friction free rotation.
AIRDRIVE SHAFT has a non contact structure between the mainshaft and the pinion gear. In addition to this, both ends of pinion gear are now supported with bearings to relay the crank power from the handle to the rotor with a higher level of efficiency. By adding high quality collars to the mainshaft, rotational noise has been reduced significantly.
AIRDRIVE SHAFT creates the feel of smooth, quiet rotation and provides anglers with torque and power.

The Mag Sealed principle is based on special magnetic oil, which has been developed by the NASA to transport fuel to the space ships based on the magnetic principle. Such oil for reel production is not available in the market. It has to be manufactured under most difficult circumstances. The embedded ferric oxide, which is necessary for the magnetic field, has a diameter of 1/100.000mm.

The molecules in this new "metal oil" are capable of changing. If they are exposed to a magnetic field, they change their shape and the oil forms a fluid seal.
Such a seal, based on the principle of liquid magnetic oil produces nearly no friction, isolates perfectly and prevents even penetration of dust particles.
The big challenge for the DAIWA engineers was the development of a reel, which is designed for the principle of the magnetic oil to generate a kind of liquid membrane that prevents water penetration.
The Mag Sealed design is based on the purpose to keep water away from a spinning reel. First of all for sea anglers this is an amazing idea - since delivers a longer life span; no corrosion and better, pro longed function. If salt water penetrates the reel and dries, it crystallizes, corrodes the gearing and affects the ball bearings. Mag Sealed halts the travel of salt particles.

A smoothly rotating line roller reduces friction between the fishing line and the reel, improving casting performance and line longevity. However, if salt or dirt particles penetrate the line roller, friction increases, leading to rough and inefficient operation. Daiwa's Magsealed line roller utilizes magnetic oil to form a protective barrier, preventing the intrusion of water, salt, and dirt. This innovation ensures continuous smooth rotation, reducing wear on both the roller and the fishing line. The result is enhanced durability and a seamless fishing experience, even under demanding conditions.

Daiwa’s Magsealed technology has continuously evolved, bringing innovation to new components of the reel. First applied to the main shaft, then the line roller, it has now been integrated into the ball bearing, marking a groundbreaking advancement in fishing reel design. By incorporating Magsealed oil into the ball bearing, Daiwa has created an almost frictionless, waterproof barrier that prevents contaminants from affecting the bearing's movement. This breakthrough ensures an extended lifespan and consistently smooth performance over time, revolutionizing the fishing tackle industry.

An evolution of Daiwa’s renowned Digigear system, Tough Digigear is designed for maximum strength, smoothness, and efficiency. By refining every detail—including gear diameter, thickness, tooth shape, and size—Daiwa has created a stronger, more durable gearing system that enhances both power transfer and longevity. Machine-cut for ultimate precision, Tough Digigear ensures silky-smooth rotation and increased mechanical efficiency, providing anglers with a reel that performs flawlessly under pressure. With improved materials and larger gear components, it delivers exceptional reliability for long-lasting performance in any fishing environment.

LC Brake Concept – Long Cast Power with a Crisp Feel: Designed for anglers who demand distance and control, the LC brake concept delivers exceptional long-range casting performance, especially in the final stretch of the cast. Optimized for medium to heavy lures, it responds dynamically to powerful rod action, translating energy into impressive flight distance. The result is a sporty, satisfying casting feel that elevates every session on the water.

LT Concept – Light & Tough Redefined: The LT (Light & Tough) concept represents a new standard in compact spinning reel design. Every detail—from the body and spool to the handle—has been meticulously engineered for weight reduction, while maintaining strength and durability where it matters most. By refining the gear system and housing structure with advanced materials and design, LT achieves the perfect balance between lightweight handling and long-term toughness. It’s a concept built for anglers who demand performance without compromise.
